DC Fast Charge
flash_on
Electrise Nova
DC FAST CHARGE
60 kW
verifiedMADE IN TURKEY
DC Fast Charging Station
Electrise Nova Commercial Charging Station
Scalable Modular DC Charging for Urban Sites
bolt
Single or Dual CCS2 Output & 10" TFT Touchscreen
Charging with single or dual CCS2 options and maximum power on one vehicle. 10" capacitive touchscreen, RFID/NFC, and OCPP 1.6J support.
Model Selection
Power
60 kW
Socket
Single or dual CCS2
Cable
4.5 m
Protection
IP54
infoProduct Description
Electrise Nova is a DC fast charging station developed for urban commercial sites and parking. It can be adapted to site needs with a single or dual socket option. Power distribution per socket depends on the selected configuration and the vehicle.
starKey Features
- check_circle Single or dual CCS2 socket option
- check_circle DC charging solution for commercial sites
thermostatEnvironmental Conditions
Operating Temperature
-30°C ~ +55°C
shield
Protection Class
IP54 / IK08
Humidity
<95% relative humidity
verified_userCertifications & Compliance
check_circleCE
check_circleIEC 61851-23
check_circleIEC 62196-3
check_circleIP54 / IK08
check_circleOCPP 1.6J
check_circleTSE Certified
boltElectrical Specs
Input valuesTo be shared with the current technical datasheet
outletOutput Specs
Max output power60 kW
Socket optionSingle or dual CCS2
Detailed output valuesTo be shared with the current technical datasheet
constructionMechanical
ProtectionIP54
ImpactIK08
CoolingFan cooling
Dimensions (W×D×H)740×970×1750 mm
touch_appInterface & Connectivity
Display10" Capacitive Touch TFT LCD
AuthenticationRFID / NFC / QR Code
ConnectionEthernet, GPRS/3G/LTE
Get a Quote for Electrise Nova
Request a quote from our team for the device, installation scope, and project timeline.
